Editing Pipelines#

Editing Pipelines in the Platform SDK follows the structure and conventions that you’re already familiar with in the UI, while offering an extensible, programmatic interaction with pipeline objects.

For more details on Pipeline interaction and usage in the UI, refer to the StreamSets Platform Documentation for pipelines.

Hint

All of the examples below have focused on stages for SDC pipelines, however streamsets.sdk.sch_models.SchStStage instances could be swapped into these examples for Transformer pipelines without issue.

Retrieving An Existing Pipeline#

In the Pipeline UI, you can see your existing Pipelines, and click into them as necessary, seen below

The streamsets.sdk.ControlHub.pipelines attribute can be used to retrieve all your Pipelines. This attribute returns a streamsets.sdk.utils.SeekableList of streamsets.sdk.sch_models.Pipeline objects:

sch.pipelines

Alternatively, you can retrieve specific pipelines by specifying pipeline_id, name, version, or commit_id to filter the pipeline results when calling the streamsets.sdk.utils.SeekableList.get() or streamsets.sdk.utils.SeekableList.get_all() methods:

pipeline = sch.pipelines.get(name='Test Pipeline')
all_version_1_pipelines = sch.pipelines.get_all(version='1')

pipeline
all_version_1_pipelines

Output:

# pipeline
<Pipeline (pipeline_id=5b67c7dc-729b-43cc-bee7-072d3feb184b:admin, commit_id=491cf010-da8c-4e63-9918-3f5ef3b182f6:admin, name=Test Pipeline, version=1)>

# all_version_1_pipelines
[<Pipeline (pipeline_id=88d58863-7e8b-4831-a929-8c56db629483:admin,
            commit_id=600a7709-6a13-4e9b-b4cf-6780f057680a:admin,
            name=Test Pipeline,
            version=1)>,
 <Pipeline (pipeline_id=5b67c7dc-729b-43cc-bee7-072d3feb184b:admin,
            commit_id=491cf010-da8c-4e63-9918-3f5ef3b182f6:admin,
            name=Test Pipeline 2,
            version=1)>]

Adding Stages To An Existing Pipeline#

Once the pipeline is created, you can add stages to it using the Pipeline Canvas UI, seen below:

To add stages to an existing pipeline using the SDK, utilize the streamsets.sdk.sch_models.Pipeline.add_stage() method - see the API reference for this method for details on the arguments this method accepts.

As shown in the image above, the simplest type of pipeline directs one origin into one destination. To recreate the example above via the SDK, you would use the Dev Raw Data Source origin and Trash destination, respectively:

dev_raw_data_source = pipeline.add_stage('Dev Raw Data Source')
trash = pipeline.add_stage('Trash')

Note

Dev Raw Data Source origin cannot be used in Transformer for Snowflake pipelines. Instead, use Snowflake Table or Snowflake Query

Once the desired stages have been added to the pipeline, you can connect them to the other stages in the pipeline as detailed in the Connecting the Stages section.

Retrieving Existing Stages In a Pipeline#

When working with an existing streamsets.sdk.sch_models.Pipeline instance that you want to update, the first step will be retrieving the stage instances to be modified. To retrieve the streamsets.sdk.sch_models.SchSdcStage instances you want to update, utilize the stages attribute for a pipeline. This will return a streamsets.sdk.utils.SeekableList of stages that can filtered on specific attributes like label, instance_name, stage_type, stage_name or any of the other various attributes.

Keeping with the example from the screenshot in the above section, you could execute any of the following commands to retrieve the stages in the pipeline:

# Retrieve the Dev Raw Data Source origin in various ways
dev_raw_data_source = pipeline.stages.get(label='Dev Raw Data Source 1')
dev_raw_data_source = pipeline.stages.get(instance_name='DevRawDataSource_1')
dev_raw_data_source = pipeline.stages.get(stage_type='SOURCE')
dev_raw_data_source = pipeline.stages.get(stage_name='com_streamsets_pipeline_stage_devtest_rawdata_RawDataDSource')

# Retrieve the Trash destination in various ways
trash = pipeline.stages.get(label='Trash 1')
trash = pipeline.stages.get(instance_name='Trash_1')
trash = pipeline.stages.get(stage_type='TARGET')
trash = pipeline.stages.get(stage_name='com_streamsets_pipeline_stage_destination_devnull_NullDTarget')

If you need to retrieve all stages from a pipeline that match a certain criteria, use the streamsets.sdk.utils.SeekableList.get_all() method:

# Retrieve ALL destination stages, for example
destination_stages_list = pipeline.stages.get_all(stage_type='TARGET')

Copy the Lanes of a Stage#

When working with an existing streamsets.sdk.sch_models.SchSdcStage instance, you can copy it’s input and output lanes to another streamsets.sdk.sch_models.SchSdcStage instance within the same Pipeline.

To copy input lanes in the SDK, simply pass in the streamsets.sdk.sch_models.SchSdcStage object that you wish to copy into the streamsets.sdk.sch_models.SchSdcStage.copy_inputs() method. In order to override all the input lanes of the current stage with the input lanes of the passed in streamsets.sdk.sch_models.SchSdcStage object, simply set override to True within the streamsets.sdk.sch_models.SchSdcStage.copy_inputs() method:

# copy input lanes of dev_identity into data_parser
data_parser.copy_inputs(dev_identity)
# override data_parser's input lanes with that of dev_identity
data_parser.copy_inputs(dev_identity, override=True)

To copy output lanes in the SDK, simply pass in the streamsets.sdk.sch_models.SchSdcStage object that you wish to copy into the streamsets.sdk.sch_models.SchSdcStage.copy_outputs() method.

# copy output lanes of dev_identity into data_parser
data_parser.copy_outputs(dev_identity)

Note

The streamsets.sdk.sch_models.SchSdcStage.copy_inputs() and streamsets.sdk.sch_models.SchSdcStage.copy_outputs() methods only work for stages within the same streamsets.sdk.sch_models.Pipeline or streamsets.sdk.sch_models.PipelineBuilder instance.

Disconnecting Stages In a Pipeline#

To disconnect stages on the Pipeline Canvas in the UI, click on the stage’s connection and click the Trash icon on the pop-up that appears, shown below:

To disconnect output lanes in the SDK, simply pass in the streamsets.sdk.sch_models.SchSdcStage object to disconnect into the streamsets.sdk.sch_models.SchSdcStage.disconnect_output_lanes() method. In order to disconnect all stages receiving output from a specific stage, simply set all_stages to True within the streamsets.sdk.sch_models.SchSdcStage.disconnect_output_lanes() method:

# disconnect dev_raw_data_source from trash
dev_raw_data_source.disconnect_output_lanes(stages=[trash])
# disconnect all stages receiving output from the dev_raw_data_source stage
dev_raw_data_source.disconnect_output_lanes(all_stages=True)

To disconnect input lanes in the SDK, simply pass in the streamsets.sdk.sch_models.SchSdcStage object to disconnect into the streamsets.sdk.sch_models.SchSdcStage.disconnect_input_lanes() method. In order to disconnect a specific stage from all other stages it receives input from, simply set all_stages to True within the streamsets.sdk.sch_models.SchSdcStage.disconnect_input_lanes() method:

# disconnect trash from dev_raw_data_source
trash.disconnect_input_lanes(stages=[dev_raw_data_source])
# disconnect trash from all other stages it receives input from
trash.disconnect_input_lanes(all_stages=True)

Note

It is not necessary to call both streamsets.sdk.sch_models.SchSdcStage.disconnect_output_lanes() and streamsets.sdk.sch_models.SchSdcStage.disconnect_input_lanes() to break the connection between two stages. Calling just one of these methods will disconnect the stages from one another.

Removing Stages From An Existing Pipeline#

Once a stage has been added, you can remove that stage using the Pipeline Canvas UI, seen below:

To remove stages from an existing pipeline using the SDK, utilize the streamsets.sdk.sch_models.Pipeline.remove_stages() method - see the API reference for this method for details on the arguments this method accepts.

To use the SDK to delete the stage as shown in the example above, you would delete the Trash destination as seen below:

pipeline.remove_stage(trash)

Note

Removing a stage from an existing streamsets.sdk.sch_models.Pipeline instance also removes all output & input lane references that any connected stages had to this stage.
